The Tyre Equipment Company Ltd

Data Product Code: QUBE1B

A newly developed Bluetooth enabled QUBE for workshops and garages the robust yet attractive ACCURA QUBE has the market boxed off for fast accurate inflation and now the unit has become SMART with this latest Bluetooth enabled model.

Designed to connect to the new PCL Workshop Connect App, operators of the Bluetooth enabled ACCURA QUBE can build a database of inflation data through the apps reporting mechanism - each inflation is recorded and downloaded as PDF and CSV file.

Ideal for HGV roadside tyre maintenance, the Bluetooth enabled model features a 15-metre operating range, allowing the operator to keep out of harm’s way in case of tyre failure during inflation.

• Space-saving and lightweight design
• Fast accurate inflation / deflation rates
• Ceramic sensor ensures accuracy to ± 0.5% of full sale reading
• Guaranteed accuracy - supplied with calibration certificate
• Pre-set function enables the operator to carry out other tasks during the inflation/ deflation process
• Standalone solution or can be retro-fitted around existing equipment
• Bluetooth enabled – works with the PCL Workshop Connect App
• 15-metre Bluetooth range allows user to inflate tyre from a distance

Users of the Bluetooth enabled QUBE can download the free PCL Workshop Connect app and can benefit from:

• Quick input of vehicle information
• PDF output with before and after tyre pressures
• CSV output to build client data
• Flat/damaged tyre and over inflation notifications
• Security enabled pairing
• Emergency stop function
• 100% standard inflation control from a 15-metre distance

Display Type    Digital
Hose Length    5 m / 16 ft
Tyre Valve Connection    Euro Clip-on
Calibration    0-174 psi / 0-12 bar
Display Resolution    0.1 bar / 1 psi
Accuracy    +/- 0.08 bar
Maximum Inlet Pressure    218 psi / 15 bar
Flow Rate    2500 l/min @ 10 bar supply
Temperature Range    -20°C to 70°C

Bluetooth Enabled Accura Qube Tyre Inflator Data Sheet

QUBE-Quick-Start-Manual.pdf
